Migrating from gymnasium

sekai keeps gymnasium's mental model (environments, spaces, wrappers, a registry, vector envs), so most code ports line by line. This page maps the API, shows how to use sekai environments with gymnasium-based libraries (and the reverse), and lists the differences that change behaviour.

pip install "sekai[gymnasium]"   # the bridge needs gymnasium >= 1.0

API mapping

gymnasium	sekai
gym.make("CartPole-v1")	sekai.make("CartPole-v1")
gym.make(id, render_mode="rgb_array"), env.render()	renderer = CartPoleRenderer(), renderer.render(env) (Rendering)
obs, info = env.reset(seed=0)	result = env.reset(seed=0) → result.observation, result.info
obs, reward, terminated, truncated, info = env.step(a)	result = env.step(a) → result.observation, .reward, .terminated, .truncated, .info
terminated or truncated	result.done
env.np_random	env.rng
super().reset(seed=seed) inside reset()	self._set_rng(seed)
self.np_random inside the env	self.rng
env.unwrapped	env.unwrapped
env.get_wrapper_attr(name)	env.get_attr(name)
gym.spaces.Box, Discrete, MultiDiscrete, MultiBinary, Dict, Tuple	sekai.Box, sekai.Discrete, ... (same arguments)
gym.spaces.Sequence(space, stack=False)	sekai.Sequence(space, max_length=None, stack=False)
(none)	sekai.MaskedBox: a padded set with a validity mask (Variable-size observations)
gym.spaces.utils.flatten(space, x)	sekai.spaces.flatten(space, x)
gym.register(...) / gym.spec(id) / gym.pprint_registry()	sekai.register(...) / sekai.spec(id) / sekai.pprint_registry()
gym.make_vec(id, n, vectorization_mode="sync")	sekai.make_vec(id, n, vectorization_mode="sync")
gym.make_vec(id, n, vectorization_mode="async") (subprocesses)	sekai.make_vec(id, n, vectorization_mode="proc")
gym.make_vec(id, n, vectorization_mode="vector_entry_point")	sekai.make_vec(id, n, vectorization_mode="native") ("vector_entry_point" is accepted too); both are the default when the env registers one
gym.register(id, ..., vector_entry_point=...), a gym.vector.VectorEnv subclass	sekai.register(id, ..., vector_entry_point=...), a sekai.NativeVecEnv subclass
gym.vector.SyncVectorEnv / AsyncVectorEnv	sekai.SyncVecEnv / sekai.ProcVecEnv
(none)	sekai.AsyncVecEnv: asyncio, for I/O-bound envs
envs.single_observation_space / envs.observation_space	vec.observation_space / vec.batch_observation_space
infos["episode"]["r"][i] (vector)	infos[i]["episode"].episode_return
gymnasium.utils.env_checker.check_env(env) (raises)	sekai.check_env(env) (returns a list of issues)
gym.wrappers.RecordVideo	sekai.rendering.RecordFrames + save()
an action_masks() method for sb3-contrib's MaskablePPO	an action_mask() method, forwarded as action_masks() by to_gymnasium()
PettingZoo ParallelEnv	sekai.MultiAgentEnv, bridged with to_pettingzoo() / from_pettingzoo()

Wrappers

Most wrappers exist under the same name. Argument names that differ:

gymnasium	sekai
Autoreset(env)	AutoReset(env); also sets info["final_observation"]
RecordEpisodeStatistics(env, buffer_length=100, stats_key="episode")	RecordEpisodeStatistics(env, tracker=None, deque_size=100); info["episode"] is an EpisodeStats
FrameStackObservation(env, stack_size, padding_type="reset")	FrameStackObservation(env, num_stack, padding="reset"); padding="zeros" for gymnasium's "zero" (no custom padding value); any batchable space, Dict included
TransformObservation(env, func, observation_space)	TransformObservation(env, func, new_observation_space=None)
ClipReward(env, min_reward=None, max_reward=None)	ClipReward(env, min_reward=-inf, max_reward=inf); None also leaves a side unbounded, and the bounds are floats (no arrays)
OrderEnforcing(env, disable_render_order_enforcing=False)	OrderEnforcing(env) (sekai envs do not render)
FilterObservation(env, filter_keys)	FilterObservation(env, keys)
TimeAwareObservation(env, flatten=True, normalize_time=False, dict_time_key="time")	TimeAwareObservation(env, max_episode_steps=None, normalize_time=True, dict_key="time")
DelayObservation(env, delay)	DelayObservation(env, delay, padding="zeros") (or "reset")
StickyAction(env, repeat_action_probability, repeat_action_duration=1)	StickyAction(env, repeat_action_probability)
MaxAndSkipObservation(env, skip=4)	ActionRepeat(env, repeat) (sums rewards; no frame max-pooling)

TimeLimit, ClipAction, RescaleAction, FlattenObservation, NormalizeObservation, NormalizeReward, TransformReward(env, func), RescaleObservation and DtypeObservation take the same arguments. (sekai 0.1 called the callable of TransformObservation and TransformReward fn; fn= still works until sekai 0.3, with a DeprecationWarning.) sekai's NormalizeObservation also accepts keyword-only stats=, halflife= and clip=, and normalises Dict observations part by part. DelayAction, ActionMaskObservation and PadSequenceObservation have no gymnasium counterpart; see Wrappers.

Side by side

sekaigymnasium

import sekai

env = sekai.make("CartPole-v1")
env.action_space.seed(0)
result = env.reset(seed=0)
total = 0.0
while not result.done:
    result = env.step(env.action_space.sample())
    total += result.reward
print(total)  # 18.0

import gymnasium as gym

env = gym.make("CartPole-v1")
env.action_space.seed(0)
obs, info = env.reset(seed=0)
total, done = 0.0, False
while not done:
    obs, reward, terminated, truncated, info = env.step(env.action_space.sample())
    total += reward
    done = terminated or truncated
print(total)  # 18.0

The dynamics, seeding and spaces are identical, so both print the same return.

A custom environment:

sekaigymnasium

import numpy as np
import sekai


class Drift(sekai.Env[np.ndarray, np.intp]):
    def __init__(self):
        self.observation_space = sekai.Box(-10.0, 10.0, shape=(1,))
        self.action_space = sekai.Discrete(2)

    def reset(self, *, seed=None, options=None):
        self._set_rng(seed)
        self.x = self.rng.normal()
        return sekai.ResetResult(np.array([self.x], np.float32), {})

    def step(self, action):
        self.x += (1 if action else -1) * 0.5 + self.rng.normal(0.0, 0.1)
        done = abs(self.x) > 5
        obs = np.array([np.clip(self.x, -10, 10)], np.float32)
        return sekai.StepResult(obs, -abs(self.x), done, False, {})


print(sekai.check_env(Drift()))  # []

import gymnasium as gym
import numpy as np


class Drift(gym.Env):
    def __init__(self):
        self.observation_space = gym.spaces.Box(-10.0, 10.0, shape=(1,))
        self.action_space = gym.spaces.Discrete(2)

    def reset(self, *, seed=None, options=None):
        super().reset(seed=seed)
        self.x = self.np_random.normal()
        return np.array([self.x], np.float32), {}

    def step(self, action):
        self.x += (1 if action else -1) * 0.5 + self.np_random.normal(0.0, 0.1)
        done = abs(self.x) > 5
        obs = np.array([np.clip(self.x, -10, 10)], np.float32)
        return obs, -abs(self.x), done, False, {}


from gymnasium.utils.env_checker import check_env
check_env(Drift())  # raises on failure

A vectorised loop:

sekaigymnasium

import numpy as np
import sekai

vec = sekai.VecRecordEpisodeStatistics(
    sekai.make_vec("CartPole-v1", num_envs=4, vectorization_mode="sync")
)
actions = vec.batch_action_space
actions.seed(0)
result = vec.reset(seed=0)
for _ in range(100):
    result = vec.step(actions.sample())
    for i in np.flatnonzero(result.dones):
        episode_return = result.infos[i]["episode"].episode_return
        last_obs = result.infos[i]["final_observation"]
        # result.observations[i] is already the first obs of the next episode
vec.close()

import gymnasium as gym
import numpy as np

envs = gym.wrappers.vector.RecordEpisodeStatistics(
    gym.make_vec("CartPole-v1", num_envs=4, vectorization_mode="sync")
)
envs.action_space.seed(0)
obs, infos = envs.reset(seed=0)
for _ in range(100):
    obs, rewards, terminations, truncations, infos = envs.step(envs.action_space.sample())
    if "episode" in infos:
        for i in np.flatnonzero(infos["_episode"]):
            episode_return = infos["episode"]["r"][i]
    # next-step autoreset (the default): on the following step, a finished sub-env
    # returns its reset observation with reward 0 and ignores its action
envs.close()

Using sekai envs with gymnasium libraries

sekai.compat.to_gymnasium(env) wraps any sekai env (including a wrapper stack) as a gymnasium.Env: spaces are converted, results become tuples, seeds pass through.

import sekai
from sekai.compat import to_gymnasium

gym_env = to_gymnasium(sekai.make("Portfolio-v0"))
print(type(gym_env).__name__, gym_env.action_space)  # SekaiToGymnasium Box(0.0, 1.0, (6,), float32)
obs, info = gym_env.reset(seed=0)
print(sorted(obs))  # ['returns', 'weights']

from gymnasium.utils.env_checker import check_env as gym_check_env
gym_check_env(gym_env)  # passes

Training with Stable-Baselines3

pip install "sekai[gymnasium]" stable-baselines3

PPO on CartPole, through the bridge. 50k steps take about 30 seconds on a laptop CPU and reach a mean return near the maximum of 500:

from stable_baselines3 import PPO
from stable_baselines3.common.env_util import make_vec_env

import sekai
from sekai.compat import to_gymnasium

vec_env = make_vec_env(lambda: to_gymnasium(sekai.make("CartPole-v1")), n_envs=4, seed=0)
model = PPO("MlpPolicy", vec_env, verbose=0, seed=0)
model.learn(total_timesteps=50_000)

env = to_gymnasium(sekai.make("CartPole-v1"))
returns = []
for seed in range(10):
    obs, _ = env.reset(seed=seed)
    done, total = False, 0.0
    while not done:
        action, _ = model.predict(obs, deterministic=True)
        obs, reward, terminated, truncated, _ = env.step(action)
        total += float(reward)
        done = terminated or truncated
    returns.append(total)
print(f"PPO mean return over 10 episodes: {sum(returns) / len(returns):.1f}")  # ~ PPO mean return over 10 episodes: 493.5

Dict observations, like Portfolio-v0's, need SB3's MultiInputPolicy. SB3's own check_env accepts every finance environment. For most of them it only adds advice, such as using a symmetric [-1, 1] action space, which RescaleAction provides. Market-v0 and LimitOrderBook-v0 are the exception: their MaskedBox entry becomes a Dict inside the observation Dict, and SB3 does not support nested observation spaces (check_env warns about it, and MultiInputPolicy raises NotImplementedError). Flatten those two first, as shown below.

import numpy as np
from stable_baselines3.common.env_checker import check_env as sb3_check_env

portfolio = sekai.make("Portfolio-v0", n_assets=3, episode_length=63)
env = to_gymnasium(sekai.RescaleAction(portfolio, -1.0, 1.0))
sb3_check_env(env)  # passes (SB3 still suggests flattening the 2-D "returns" entry)

model = PPO("MultiInputPolicy", env, n_steps=512, batch_size=64, verbose=0, seed=0)
model.learn(total_timesteps=20_000)


def evaluate(policy, episodes=50):
    totals = []
    for seed in range(1000, 1000 + episodes):
        obs, _ = env.reset(seed=seed)
        done, total = False, 0.0
        while not done:
            obs, reward, terminated, truncated, _ = env.step(policy(obs))
            total += reward
            done = terminated or truncated
        totals.append(total)
    return float(np.mean(totals))


ppo = evaluate(lambda obs: model.predict(obs, deterministic=True)[0])
equal_weight = evaluate(lambda obs: np.ones(4, dtype=np.float32))
print(f"PPO {ppo:+.4f}, equal weight {equal_weight:+.4f}")  # ~ PPO +0.0075, equal weight +0.0086

A 20k-step run is nowhere near converged; the closed-form and heuristic baselines on the finance page are the bar a learned policy has to clear.

Nested observations: flatten first

For Market-v0 and LimitOrderBook-v0, wrap the sekai env in sekai.FlattenObservation before converting it, and train with MlpPolicy:

market = to_gymnasium(sekai.FlattenObservation(sekai.make("Market-v0")))
print(type(market.observation_space).__name__)  # Box

model = PPO("MlpPolicy", market, verbose=0, seed=0)
model.learn(total_timesteps=2_048)

The flattened vector is the same one gymnasium's FlattenObservation builds from the converted env, because to_gymnasium() keeps the Dict key order.

Action masks

When the sekai env has an action_mask() method, the gymnasium env gets an action_masks() method returning the mask flattened to one boolean array, the layout sb3-contrib's MaskablePPO expects. Wrappers forward action_mask(), so this still works through FlattenObservation. LimitOrderBook-v0 masks orders that would breach its inventory limit (pip install sb3-contrib):

from sb3_contrib import MaskablePPO

lob = to_gymnasium(sekai.FlattenObservation(sekai.make("LimitOrderBook-v0")))
lob.reset(seed=0)
print(lob.action_space, lob.action_masks().shape)  # MultiDiscrete([6 6 3]) (15,)

model = MaskablePPO("MlpPolicy", lob, verbose=0, seed=0)
model.learn(total_timesteps=2_048)  # every action it samples is allowed by the mask

Rendering

Pass a renderer to get gymnasium's render_mode="rgb_array", so tools like gymnasium.wrappers.RecordVideo work:

from sekai.envs.classic_control import CartPoleRenderer

gym_env = to_gymnasium(sekai.make("CartPole-v1"), renderer=CartPoleRenderer())
gym_env.reset(seed=0)
print(gym_env.render_mode, gym_env.render().shape)  # rgb_array (400, 600, 3)
print(gym_env.metadata)  # {'render_modes': ['rgb_array'], 'render_fps': 50}

For a text renderer pass render_mode="ansi" as well. Other modes raise ValueError, "human" included: sekai renderers return frames instead of opening a window. To watch the frames, wrap the converted env in gymnasium.wrappers.HumanRendering (needs pygame).

Using gymnasium envs in sekai

sekai.compat.from_gymnasium(env) goes the other way, so any gymnasium environment (Atari, MuJoCo, Box2D, your own) can use sekai's wrappers, vector envs, statistics and checker:

import gymnasium as gym
import sekai
from sekai.compat import from_gymnasium

env = from_gymnasium(gym.make("Acrobot-v1"))
print(env.observation_space, env.action_space)  # Box([-1.0, -1.0, -1.0, -1.0, -12.566371, -28.274334], [1.0, 1.0, 1.0, 1.0, 12.566371, 28.274334], (6,), float32) Discrete(3)
print(sekai.check_env(env))  # []

vec = sekai.SyncVecEnv([lambda: from_gymnasium(gym.make("Acrobot-v1")) for _ in range(4)])
print(vec.reset(seed=0).observations.shape)  # (4, 6)
vec.close()

The gymnasium env keeps its own generator: seeds given to reset() go straight to it and env.rng is its np_random. gymnasium only takes int seeds, so a NumPy integer seed is passed on as an int, and reset(seed=generator) keeps sekai's meaning by making that Generator the gymnasium env's np_random. To render such an env, create it with gymnasium's render_mode and use sekai.compat.GymnasiumRenderer, which calls the gymnasium env's own render():

gymnasium's classic-control environments draw with pygame, which sekai[gymnasium] does not install; pip install "gymnasium[classic-control]" adds it for this example.

from sekai.compat import GymnasiumRenderer

env = from_gymnasium(gym.make("CartPole-v1", render_mode="rgb_array"))
env.reset(seed=0)
print(GymnasiumRenderer().render(env).shape)  # (400, 600, 3)

space_to_gymnasium() and space_from_gymnasium() convert individual spaces. A Dict keeps its key order in both directions (a gymnasium Dict built from a plain dict sorts its keys), so flattened observations line up on both sides. A Sequence becomes gymnasium's Sequence, which has no length bound, so max_length is dropped; a MaskedBox becomes a gymnasium Dict of values and mask, and comes back as a plain Dict:

from sekai.compat import space_to_gymnasium

print(space_to_gymnasium(sekai.Sequence(sekai.Box(0.0, 1.0, shape=(2,)), max_length=8)))  # Sequence(Box(0.0, 1.0, (2,), float32), stack=False)
print(space_to_gymnasium(sekai.MaskedBox(0.0, 1.0, shape=(2,), max_size=8)))  # Dict('values': Box(0.0, 1.0, (8, 2), float32), 'mask': MultiBinary((8,)))

Multi-agent: PettingZoo

The same bridge exists for multi-agent environments: sekai.compat.to_pettingzoo(env) exposes a sekai.MultiAgentEnv as a PettingZoo ParallelEnv, and from_pettingzoo(parallel_env) wraps a PettingZoo parallel environment as a MultiAgentEnv. Install it with pip install "sekai[pettingzoo]"; see Multi-agent.

Differences that change behaviour

Vector autoreset is same-step

gymnasium ≥ 1.0 vector envs default to next-step autoreset. sekai resets a finished sub-env inside the same step(): observations[i] already belongs to the new episode and the terminal observation is in infos[i]["final_observation"]. Remove any code that skips the dummy step after an episode ends, and bootstrap truncated episodes from final_observation. See Autoreset.

vectorization_mode=\"async\" means asyncio

In gymnasium, "async" starts subprocesses. In sekai, "async" is AsyncVecEnv (asyncio, one process) and "proc" is the subprocess backend.

Results are dataclasses

obs, reward, terminated, truncated, info = env.step(a) raises TypeError with sekai, because StepResult is not iterable. Use the fields, or go through to_gymnasium() when a library needs tuples.

No render mode on the env

sekai.make() takes no render_mode; any keyword argument goes to the environment's constructor. Create a renderer instead.

Seeding details

Seeding an env works as in gymnasium (reset(seed=s) then unseeded reset()s continue the stream). Vector envs differ: an int seed is expanded into independent child seeds rather than seed + i. Pass a list for explicit per-env seeds.

Vector infos are lists

infos is a list with one dict per sub-env, not a dict of arrays with _key masks. sekai.stack_infos(infos) gives a dict of arrays when you need one.
